Abstract
M.Sc.
The study looks into the sediment-bound metals (Fe, Mn, Cu, Cr, Cd, Co, Pb, Ni, Zn and Hg) of the Leeu/Taaibospruit catchment, which is impacted by agricultural, industrial and urban development. A number of chemical procedures, including total metal determination, the Tessier-sequential extraction scheme, the BCR Protocol, evaluation of the % TOC and determination of AVS to SEM ratios were applied to sediment samples collected from eight sites along the two rivers in the study area. Samples were collected during both high flow (summer) and low flow (winter) conditions.
Following the chemical characterisation, bioaccumulation testing was conducted by exposing chironomid larvae to the sediment samples collected in from the study sites and determining their metal uptake relative to control specimens in uncontaminated sediments. These bioaccumulation results were then considered in conjunction with the chemical parameters in an attempt to identify any trends and correlations.
Significant spatial and temporal differences were found in the metal concentrations from the study area. The total extraction results indicated that abundant amounts of Cr and Fe are present throughout the system. This was expected based on the make-up of the underlying geology. In addition, one of the sites, which is in close proximity to the town of Sasolburg, was identified as a potentially contaminated site. This site had significantly higher concentrations of Zn, Cu, Pb and, most notably, Hg when compared to the other sites. The elevated metal concentrations are most evident in samples collected under low flow conditions, but are also seen in the high flow Hg concentrations.
Sequential extractions showed that Fe and Cr are concentrated in the residual phases of the sediment. Copper is largely present in the oxidisable fraction under low flow
conditions, but also has considerable residual and reducible chemical forms. Manganese and Zn are distributed among all the different chemical phases and are therefore likely to be readily available for uptake by benthic organisms.
The TOC was found to be highest during low flow conditions and at those sites with observable amounts of organic debris from the surrounding reeds and other vegetation. The AVS/SEM ratios were used to predict that due to the formation of insoluble metal sulphides, Cd, Cu, Hg, Ni, Pb and Zn are unlikely to be bioavailable at certain sites, i.e. the contaminated site 1 and at site 5, which only has agricultural impacts.
In general, the bioaccumulation of Fe, Co, Ni, Cr and Mn was higher in the test larvae than the control larvae. Bioaccumulation of Cu, Pb, Zn and Hg levels were only higher than the control worms at sites where contamination was suspected to have taken place. Average bioaccumulation factors indicated that Hg is the metal that is most readily available for bioaccumulation, followed by Cu, Zn and Mn. All of these metals were bioconcentrated in the tissues of the test chironomids, while levels of Fe, Ni, Cr and Pb were found to be lower in the organisms than in the sediments.
Although many of the chemical fractions were found to correlate significantly with the uptake of the different metals, the best overall correlation existed between the bioaccumulated metal and the total non-residual fraction. In fact, the sum of the first four steps of the Tessier-scheme correlated significantly with the bioaccumulated metal for all elements considered in the calculation, except for Pb. Additionally, the predictions made by the AVS model were found to be useful in justifying the behaviour and accumulation patterns of Hg, Zn and Cu at certain sites.
The correlations and bioavailability clearly differed spatially, temporally and among the different elements. It is therefore suggested that prediction of the bioavailability and subsequent uptake of sediment-bound metals will require as many chemical and environmental factors as possible, and should include bioaccumulation and toxicity testing in order to examine the validity and completeness of these predictions.
