Abstract
17-4 PH Stainless steel is a martensitic characterized precipitation hardened stainless steel with excellent mechanical properties that has been tailored to industrial applications such as aerospace, automobile, marine, food processing equipment, oil and gas industries and chemical processing industries. Despite the growth experienced in the use of this material, 17-4 PH stainless steels are prone to degradation due to long service use in applications that required extreme hardness and wear resistance. This limitation led to the research of property enhancement of the material using modern fabrication technique called laser metal deposition additive manufacturing technology. Laser metal deposition is a modern additive manufacturing technique used in fabricating physical components from the configuration of a 3D CAD data model using a high intensity laser beam while depositing metallic powder on a substrate one layer at a time. This process is flexible in its use as it allows addition of reinforcing particles to improve surface properties of a metallic material such as hardness and wear amongst others.
This research study presents the use of laser metal deposition process to investigate the property enhancement of 17-4 PH stainless steel through various characterization process such as microstructural evaluation, microhardness and wear test. The deposition process was carried out using Rofin Sinar Ytterbium fibre laser system of laser capacity of 3.0 kW. The reinforcement material was 17-4 PH stainless steel and tungsten metallic powder deposited on 316 stainless steel substrate. The deposition process commenced firstly with a trial-run deposition of 5 samples with multiple-track of 17-4 PH stainless steel at 50% overlapping percentage on 316 stainless steel substrate to establish process window. The reason for the trial-run was to achieve a deposition with no defects such as pores and cracks. After this was achieved, 17-4 PH stainless steel metallic powder and tungsten metallic powder were now deposited in form of multiple track at 50% overlapping percentage at high laser power and low laser power of 2600 W and 1500 W at varied tungsten powder flow rate on 316 stainless steel substrate. The microstructural evaluation, geometrical analysis, microhardness profiling and wear resistance characteristics of the deposited composites were investigated. The microstructural evolution investigation was carried out using optical microscopy (OM), scanning electron microscopy (SEM) equipped with energy dispersive spectroscopy (EDS) and x-ray diffraction (XRD). Geometrical analysis was carried out on the deposited composite samples both at high and low laser power to investigate the extent of laser...
M.Ing. (Mechanical Engineering)
