Abstract
M.Ing.
Over the past few years, fibre Bragg gratings have emerged as very important components in the photonics environment. Their discovery has greatly revolutionised the design of many complex devices, introducing simplicity and cost effectiveness. Extensive research has been invested into identifying possible areas of application for fibre Bragg gratings. This has resulted in fibre Bragg gratings finding a comfortable niche in the fields of sensors and optical communication systems.
This study focuses on the possible application of fibre Bragg gratings in wireless local area networks. Wireless local area networks are rapidly becoming a market of great potential for the investor. To sustain the impressive image of this market, research initiatives should strive to secure cost-effective solutions for the implementation of wireless local area networks. With reduced costs on wireless local area network products, the demand for these products is expected to escalate.
Research conducted at the COBRA Institute, has produced a novel concept of optically distributing data signals across a network, and later transmitting them at radio frequencies between antenna sites. This concept, earmarked for wireless local area networks, uses a fast tuneable laser source, graded index polymer optical fibre and a periodic optical filter to generate the radio frequency microwave signals. The periodic filter in this network system serves to up-convert the frequency of the signal to radio-frequency levels. The filter is an important component of the network and it is situated at the antenna site. For wireless local area networks that require broad coverage, the number of periodic optical filters deployed for the system can be high. This can have a negative impact on the cost of the network.
This research proposes a low-cost Fabry-Perot filter designed from fibre Bragg gratings, to replace the optical periodic filter discussed in the network mentioned above. The work presented in this study consolidates the design theories of Fabry-Perot filters and fibre Bragg gratings. The grating-based Fabry-Perot filter is modelled using coupled-mode theory, simulated using the transfer matrix method and fabricated via the strain controlled phase mask technique. The figures of merit that describe the spectral performance of the Fabry-Perot filter (i.e. free spectral range, minimum resolvable bandwidth, finesse and contrast factor) are compared to calculations associated with classical designs.
The final part of this study presents experimental measurements of the generated radio frequency microwave signal. The purpose of these measurements is firstly to demonstrate the feasibility of the entire concept of generating radio frequency microwave signals using optical frequency multiplication. The second goal for the measurements is to benchmark the performance of the new grating-based Fabry-Perot filter against expected results approximated through calculations. Both goals were achieved with encouraging observations.
